Bounder

• General Usage
• Options
• Known Bugs/Limitations
• History

General Usage:

1. Select several objects in a set you want to simplify.
2. Set the settings as you want (important ones include "For Each Object" and "Align To Orientation".
3. Create the bounding volumes with "Create".

Back To Top...

Options:

• Bounding Volume Type:
  Choose the type of bounding volume you want to create (Box, Chamferbox, Sphere, or Cylinder).
• Non-Uni Scale:
  Sets whether the bounding volume can be non-uniformly scaled to fit an object. Only applies to Sphere or Cylinder bounding types.
• For Each Object:
  Sets whether to create a separate bounding volume for each selected object, or a single one for the entire group.
• Link To Source:
  Links each bounding object to the original source object. Only available when "For Each Object" is ON.
• Keep Pivot:
  If on, the bounding object's pivot point will be aligned to the selected object's pivot point.
• Align To Orientation:
  If on, the bounding object will be aligned to the selected object, otherwise it will be aligned to the world, but still fit the selected object.
• Non-Renderable:
  Sets whether the bounding volume is renderable.
• Use Color:
  If on, the bounding volume's wire color will be set using the color swatch, otherwise it will match the selected object's wire color.
• Postfix:
  The bounding volumes will be named after the selected object's name, plus whatever is in this postfix text field.
• Create:
  Create bounding volumes from the current selection.

Back To Top...

Known Bugs/Limitations:

• Will crash on biped objects

Back To Top...

History:

1999.06.16 - Added option for bounding color
1999.07.14 - Added options for keeping name and color
             Added some "context awareness" for choosing likely options
1999.08.04 - Added ability to do object individualy as well as a whole
             Added orentation to the bounding boxes for use with Bips and Bones
             Added Suffix option
             Changed the way "Keep Pivot" functions
             Added non renderable toggel
1999.10.19 - Converted to 3.1
2000.09.14 - Added chamferbox, bugfix
2001.03.19 - Link To Source option
